CNC Sawjet HKNC-400J
This stone CNC Sawjet & bridge saw has everything a technologically advanced bridge saw & waterjet needs to have today: 5 interpolated axis, spindle with half inch fitting with trough-spindle lubrication, tilting table up to 85°, vacuum manipulator system for parts movement during automatic cut process, on-board camera, blade presetting and stone thickness probe.
|
Main Features Integrated Cutting System: 5-Axis Bridge Saw & 3-Axis Waterjet 1. Advanced 5-Axis Bridge Saw 360° automatic head rotation + 90° blade tilting for unlimited angular positioning Multi-process integration: Seamlessly combines cutting, drilling, milling, and engraving Complex curvature processing: Handles intricate 3D contours with production-line efficiency Cost-optimized throughput: Ideal for high-volume fabrication of stone, quartz, and advanced ceramics 2. Precision 3-Axis Waterjet Cutter Sub-millimeter accuracy on internal corners and complex geometries Industrial-grade pump: KMT-H20 JET50 super-pressure system Premium controls: Siemens PLC and servo motor integration |
|
Function Display
5-Axis CNC Integration with ESA System (Italy)
Precision Drive System
Linear ball guides + helical gear/rack transmission
Servo motor actuation
Cutting Intelligence
Manual/AutoCAD DXF hybrid workflow
Unified Sawjet & Bridge saw operation
Productivity Features
85° tilt platform → 40% faster material handling*
Visual defect mapping → 15% material waste reduction*
Nesting software → Optimized yield per slab
Premium Options
RTCP: Critical for complex 3D milling
Vein-Match: Luxury finish solution
Technical Parameters
|
TECHNICAL DATA FOR HKNC-400J |
||
|
Diameter of saw blade |
ø350-ø450 |
mm |
|
Dimension of working platform |
4150x2250 |
mm |
|
X axis stroke |
3500 |
mm |
|
Y axis stroke |
2000 |
mm |
|
Z axis stroke |
500 |
mm |
|
Max. cutting thickness |
100 |
mm |
|
Max. lifting stroke |
320 |
mm |
|
Power of saw blade motor |
26.4 |
kw |
|
Power for abrasive waterjet |
37 |
kw |
|
Max. operating water pressure |
450 |
mpa |
|
Required pressure of inflow |
0.4 |
mpa |
|
Water consumption |
11.4-16.7 |
l/min |
|
Gross weight |
10000 |
kg |
|
Dimensions (L x W x H) |
6000x3820x320 |
mm |
Attend The Exhibition
Customers'Spot
FAQ
Q: What are the main types of stone cutting machines?
A: Blok cutting machine: Suitable for cutting rough stone. It can cut large blocks of stone into thin slabs.
Water jet cutting machine: Uses high-pressure water jets to cut stone, suitable for fine cuts.
Multiwire: Uses uses diamond wire saw to cut rough stone.
CNC bridge saw: Controlled by a computer program, suitable for complex patterns, precision cutting, and engraving.
Q: How can stone machinery improve processing accuracy?
A: Utilize quality instruments: Selecting tools that are both sharp and resilient can enhance cutting accuracy.
Consistently adjust the machinery: Verify that the machinery operates in accordance with technical standards.
Enhance the program layout: By refining the CNC program, errors in the process can be minimized.
Preserve a consistent working atmosphere: Elements like temperature and moisture can influence the precision of the machinery; sustaining a stable atmosphere aids in decreasing mistakes.
Q: How does the five-axis bridge cutting machine work?
A: The working principle of a five-axis bridge saw involves five coordinated motions:
X-axis: Moves forward and backward
Y-axis: Moves left and right
Z-axis: Moves up and down for depth control
A-axis: Tilts the cutting blade
C-axis: Rotates the blade or the material
